S200C212O
Electrical number: 4608103
Product group: Stepped poles
Product number: S200C212O
Tehomet stepped poles
Tehomet stepped poles are manufactured from high quality low-silicon steel, using an environmentally friendly cold forming technology in step joints. This ensures concentricity between different sized tubes and minimal environmental loading due to the low energy consumption in the manufacturing.
Product sizing: standard SFS-EN 40-3-3
Product manufacturing: standard SFS-EN 40-5
Raw material: low-silicon steel (Si + P ≤ 0,04 %)
Zink coating: international standard EN ISO 1461 – layer thickness typically <90 μm.
Spigot: diameter 60 mm and length 100 mm
Attachment of the arm: There are two sets of screws with 3 x 120° division at the top of the pole (not in straight stepped poles) to attach the arm easily and securely.
Download product card Share link to email Report an error
Share this article
Technical specs
Weight (kg)
202
Material
steel
Pole shape
stepped
Lighting height (m)
12
Shaft top diameter (mm)
114
Arm/cross arm type
upright arm
Arm outreach/cross arm width (mm)
1500
Arm diameter (mm)
76
Spigot diameter (mm)
60
Embedding (mm)
600
Base diameter (mm)
219
Door width x height (mm)
100x400
Connection compartment internal dimensions (mm)
90x160
Distance door bottom to ground (mm)
950
EN40 capacity FI (21 m/s, CAT2, class A)
1,36
Foundation
Foundation with embedding
Embedding 600 mm
For example, we recommend the following Lujabetoni concrete bases for this product
| Product type | Electrical number | |
|---|---|---|
| Option 1 | RBJ-5B | 4607266 |
| Option 2 | RBJ-5 RST | 4607220 |
| Rubber protector for this pole and base |
360/204K | 4607407 |
Surface treatment
Surface treatment of metal parts
Zinc coating: international standard EN ISO 1461 (layer thickness typically <90 μm).
Read more about galvanizing our steel poles: Hot-dip galvanizing steel poles
The steel parts can be painted in standard RAL colors or with an easy-to-maintain and tough Plascoat coating. The standard colors of Tehomet’s steel lighting poles are shown on the Painting Service page.
